LKB-02 target flow controller

Home Products Shanghai Automation Instrumentation No. 4 Factory pressure controllers LKB-02 target flow controller

LKB-02 target flow controller

  • Category:pressure controllers
  • Inquiry Send Email

    Description

    LKB-02 target flow controller uses target sensors. It can be used in water cooling system or other fluid circuits, and it can be used with the actuator to make two-position control or alarm for pipeline water flow.
    ◇ Main technical performance:
    Environmental temperature: 5 ~ 55 ℃
    Installation position: The arrow on the shell is consistent with the direction of the water flow, and a 10D (pipe diameter) guide straight pipe is required in front of the controller.
    Installation pipeline: 1-6 "
    Setting range: 20-2000 l / min
    Pressure resistance: 2MPa
    Contact capacity: AC 250V 3A (resistive)
    Medium temperature range: 5 ~ 80 ℃
