Description
LKB-03 flow controller is used for water cooling system or other fluid circuits, and it can act as an alarm or automatic control for the water flow in the pipeline.
◇ Main technical performance:
Setting range (Setting value control range: 6 ～ 30L / min
Installation position: The arrow on the shell is consistent with the direction of the water flow. A 10D (pipe diameter) guide is required in front of the controller.
Switching difference: ≤6L / min
Repeatability error: ≤1.5L / min
Pressure resistance: 1.6MPa
Contact capacity: AC 250V 3A (resistive)
1 pair of switching contacts (with normally open and normally closed)
Environmental temperature: 5 ～ 40 ℃
Medium temperature range: 5 ～ 80 ℃
Enclosure protection level: IP54 (in accordance with GB4208)
