WTYK-11B pressure type temperature controller

Home Products Shanghai Automation Instrumentation No. 4 Factory pressure controllers WTYK-11B pressure type temperature contr

WTYK-11B pressure type temperature controller

  • Category:pressure controllers
  • Inquiry Send Email

    Description

    WTYK-11B pressure type temperature controller uses temperature-packed sensor. Can be used to cool liquid media such as water or oil.
    ◇ Single pole double throw micro switch action process:
    Terminal 1-3: Turn on when the temperature rises to the upper switching value.
    Terminal 2-3: disconnect when the temperature rises to the upper switching value.
    ◇ Main technical performance:
    ● Contact capacity
    The general specifications of the controller adopt AK1-1 type micro switch, and the rated load of the contact is DC 27V 15A.
    The 78 ℃ specification of the controller adopts WKI-6 type micro switch, and the rated load of the contact is DC 27V 10A.
    It has been proved by tests that the on-off capacity of AK1-1 and WK1-6 micro-switches can be reached: when the branch voltage is 110 volts, (1) the inductive load (time constant is 100 ms) and the on-current is 0.5 A , Breaking current is 0.5 amps. (2) Resistive load: On-current is 12.5 A, breaking current is 1 A.
    ◇ Regulations:

    ● Adjustable switching difference



    Code
    No.

    Setting valve

    Switch difference

    Set value error
    ℃

    Repeatability

    Error

    Medium highest

    Temperature

    1

    40

    1.5 ~ 4

    ±2

    1

    100℃

    2

    45

    1.5 ~ 4

    ±2

    1

    100℃

    3

    60

    1.5 ~ 4

    ±2

    1

    100℃

    4

    65

    1.5 ~ 4

    ±2

    1

    100℃

    5

    78

    4 ~ 7

    ±2

    1

    100℃

    6

    85

    1.5 ~ 4

    ±2

    1

    100℃

    7

    90

    1.5 ~ 4

    ±2

    1

    100℃

    8

    95

    2 ~ 5

    ±2

    1

    100℃

    9

    110

    2 ~ 5

    ±2

    1

    125℃

    10

    120

    2 ~ 5

    ±2

    1

    125℃

    ◇ Installation:

    ● The controller can use its threaded part to directly screw into the pipeline of the controlled medium. Attention must be paid to the seal at the installation port. The temperature-sensing package must be completely immersed in the controlled medium.

    ● The circuit wiring can be through a small plug socket, and the wiring to the switch is shown in the right figure.
